A compact, light, essential and functional bike, with a marked off-road imprint. Versatility of use at the highest levels, and great ability to move effectively and safely in all conditions, from smooth asphalt to stony ground.
SPECIFICATIONS
Compression ratio
12,5:1
Dry weight
220 kg (485 lbs.)
Total displacement
931cm3
Performance
max speed 240 Km/h
Max. torque
102 Nm (10,4 kgm) at 7.000 rpm
Max. power - rpm (at the crankshaft)
90,5 kW (123 CV) a 10.000 giri/min
Engine Type
3 cylinder, 4 stroke, 12 valve
Full specs
BECOME LUCKY AMBASSADOR
We are connecting a community, a large family that we want to bring with us on this amazing journey to-wards the future of Lucky Explorer.
By signing-up you will receive a unique referral code, with this simple link you can invite friends to register and grow your chance to become a lucky ambassador, having access to unique contents, previews and many more features we will unveil over the course of this project.
Registering will also give you the chance to comment and create conversation on our blog and receive product updates directly in your inbox.
YES!
Timing system
“D.O.H.C” with mechanical chain tensioner and DLC tappets.
Total displacement
931cm3
Compression ratio
12,5:1
Starting
Electric
Bore per stroke
81 mm x 60,2 mm
Max. power - rpm (at the crankshaft)
90,5 kW (123 CV) a 10.000 giri/min
Max. torque
102 Nm (10,4 kgm) at 7.000 rpm
Cooling system
Liquid and oil with separated radiators.
Engine management system
Integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with three injectors. Engine control unit Eldor Nemo EM 3.0Throttle body bore 47 mm diameters full ride by wire MikuniPencil-coil with ion-sensing technology, control of detonation and misfire.Torque control with four maps.
Clutch and gearbox
Wet multidisc hydraulic clutch + SCS (Smart Clutch System
Gearbox
Cyborg electroactuated gearbox + Electronic quick shift MV EAS (Electronically Assisted Shift Up & Down)
Type
3 cylinder, 4 stroke, 12 valve
Min. ground clearance
230 mm (9.05 in.)
Fuel tank capacity
20l (5.28 U.S. gal.)
Dry weight
220 kg (485 lbs.)
Trail
118 mm (4.64 in.)
Overall width
980 mm (38.58 in.)
Overall length
2.270 mm (89.37 in.)
Wheelbase
1.580 mm (62.2 in.)
Seat height
850/870 mm (33.46 / 34.25 in.)
Type
Sachs ELECTRONIC “UPSIDE DOWN” telescopic hydraulic fork with rebound – compression damping and spring preload ex-ternal and separate adjustment.
Fork
50 mm (1.97 in.)
Fork travel
220 mm (8.66 in.)
Material
Aluminium die cast twin sided swing arm
Wheel travel
210 mm (8.27 in.)
Type
Progressive, Sachs ELECTRO-NIC single shock absorber with rebound and compression damping and spring preload adjustment.
Front
Double floating disc. Ø 320 mm (Ø 12.6 in.), with steel braking disc and flangeFront brake radial-type monobloc Brembo Stylema caliper, with 4 pistons Ø 30 mm (Ø 1.18 in.)
Rear
Single steel disc with Ø 265 mm (Ø 10.43 in.) dia Brembo caliper with 2 pistons - Ø 30 mm (Ø 1.18 in.)
ABS System
Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and cornering function.
Front
Spoked, Tubeless, with alumi-nium hub and rim 2,15” x 21”
Rear
Spoked, Tubeless, with alumi-nium hub and rim 4,25” x 18”
Front
90/90 - 21
Rear
150/70 - R 18
